MIKI PULLEY
ETP-A Models
- Bore diameter : 15 mm to 100 mm
- Max. rated torque : 15500 N・m
- Concentricity : 0.05 mm
ETP-A Models
Shaft and hub can be easily and quickly coupled by tightening a clamping bolt located on the flange surface.Fastening is accomplished using fewer bolts than with mechanical systems, and there is no slotting as with mechanical systems, so high-precision coupling with a concentricity of 0.05 mm is possible.
Many variations
Steel construction is standard, but there are many variations, including simple anti-rust specifications, stainless steel specifications, and short specifications.
